Nativelink TCL script failed with errorInfo: Can't launch ModelSim-Altera Simulation software - make sure the software is properly installed and the environment variable LM_LICENSE_FILE or MGLS_LICENSE_FILE points to the correct license file. Nativelink TCL script failed with errorCode: issued_nl_message =The following additional information is provided to help identify the cause of error while running nativelink scripts= Sourced NativeLink script /home/*username*/altera_lite/16.0/quartus/common/tcl/internal/nativelink/modelsim.tclĮrror: Can't launch ModelSim-Altera Simulation software - make sure the software is properly installed and the environment variable LM_LICENSE_FILE or MGLS_LICENSE_FILE points to the correct license file.Įrror: NativeLink simulation flow was NOT successful Info: Starting NativeLink simulation with ModelSim-Altera software Quartus sim root : /home/*username*/altera_lite/16.0/quartus/eda/sim_lib Quartus root : /home/*username*/altera_lite/16.0/quartus/linu圆4/
Therefore select ‘full visibility’ in the tab Optimization Options. Optimization improves simulation speed but during debugging not all signals and variables are visible. In case a licenced version of ModelSim/QuestaSim is used optimizations it is on by default. Since our lab does not have license for Modesim Altera Edition, at this step, please choose folder modelsimasewin32aloem. In the ModelSim-Altera starter edition Enable optimization is disabled. Modelsim ASE (Altera Starter Edition) does not require a license (It is FREE). (Again, it should be something like: C:\intelFPGAlite\18.0\modelsimase\win32aloem.) 5. The folder modelsimae is for Modelsim AE (Altera Edition). If not, then browse to the directory containing the executable of the Modelsim-Altera simulator. Info: NativeLink has detected VHDL design - VHDL simulation models will be used In the Modelsim-Altera entry, the location of executable should be something like: C:\intelFPGAlite\18.0\modelsimase\win32aloem. Info: Start Nativelink Simulation process The NativeLink log file is not very informative: The tool properly analyzes and elaborates my model but refuses to perform an RTL simulation with the following error message:Įrror: Error: Can't launch ModelSim-Altera Simulation software - make sure the software is properly installed and the environment variable LM_LICENSE_FILE or MGLS_LICENSE_FILE points to the correct license file.Įrror: Error: NativeLink simulation flow was NOT successful 1.2 To automatically run EDA design input, synthesis, simulation, or timing analysis tools from the Quartus II software, you must specify the location of the executable file of the third-party EDA tool by clicking Options on the Tools menu and then clicking the EDA Tool Options option. I have encountered a problem with Quartus Prime and ModelSim-Altera. This ModelSim version supports all Altera devices supported by Quartus II.
